[DS-PDQP15AM-LM-WE]HIKVISION Wireless 180° Panoramic Detector

  • 180° panoramic coverage
  • Active IR anti-masking
  • IP65 weather resistance for outdoor application
  • Multiple enrollment methods and easy installation
  • Frequency hopping against jamming for reliable transmission
DS-PDQP15AM-LM-WE
We do not have stock available for this product
HIKVISION
Offer: 150,00 € VAT Excluded
  181,50 € VAT Included (21%)
Quantity
This product is out of stock, we can order it for you quickly, contact us:
Telephone:+34 910 35 36 71

Detection Performance
Detection Method Passive Infrared
Detection Range 15 m
Detection Angle 180°
Detection Zones 40
Detectable Speed 0.3~2m/s
Sensitivity Auto;Low
White Light Filter 20000lux
Pet Immunity Up to 40 kg (cm height)
Digital Temperature Compensation Support
Anti-masking Support
Adaptable Coverage Pattern mask included

Feature
Digital Processing Support
Sealed Optics Support
Tamper Protection Front;Rear
Environment Temperature Indicator Support
Signal Strength Indicator Support

Interface
Power Switch Power up enrolling
LED Indicator Blue(alarm), green+orange(mask)

Transmission
Transmission Technology Tri-X Wireless
Transmission Method Two-Way RF Wireless
Transmission Frequency 868MHz
Transmission Security AES-128 Encryption
Transmission Range(Free Space) 1.6Km
Frequency Hopping Support
Enrolling Method Power up;Remote ID;QR Code

Electrical Characteristics
Standard Battery Life Up to 5 years (standby time) (The battery working time can be significantly reduced at low temperatures)
Power Supply Battery powered
Battery Type CR123A × 5
Typical Voltage 3V

General
Operation Temperature -25°C to 60°C (-13°F to 140°F)
Storage Temperature -25°C to 60°C (-13°F to 140°F)
Operation Humidity 10% to 90%
IP Rate IP65
Dimension(WxHxD) 75 mm × 202 mm × 73 mm
512.5 g
Mounting Height 0.8 m to 1.2 m
Mounting Method Wall
Application Scenario Outdoor
